Corporate Availability lifecycle: May 31, 2020 - Dec 30, 2030
The flexible performance options of the Elite t655 Thin Client enables workforce productivity, while commercial-grade security features provide IT peace of mind. Built to support demanding performance requirements, this device helps end users tackle daily tasks, while versatile configuration options help optimize workspaces.
Encrypt data as it flows between the system memory and processor, protect firmware, and lock down access. The Elite t655 Thin Client features multi-layered security with AMD Memory Guard, an embedded OS, and a NIST SP800-193 component.
Organize your workspace with a wide variety of configuration options. Set it, mount it, stand it in up to six different orientations with a VESA® mount and get seamless compatibility with select docking devices and peripherals.
Enhance performance with a next gen AMD Embedded R-Series processor and up to three UHD/4K displays.
Empower your workforce with the combined power and performance of the next-gen AMD Embedded R-Series processor, a high-speed, responsive NVMe solid-state drive, and native support for up to three stunning UHD/4K displays.
Overview
[1] Multicore is designed to improve the performance of certain software products. Not all customers or software applications will necessarily benefit from the use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. AMD’s numbering is not a measurement of clock speed.
[4] Peripherals sold separately or as optional features. Compatible with E24m G4 FHD USB-C Conferencing Monitor, E24u G4 FHD USB-C Monitor, E27u G4 QHD USB-C Monitor, E27m G4 QHD USB-C Conferencing Monitor, and USB-C Dock G5.
[5] 4K content required to view 4K images. Displays are sold separately and are not included.
[1] Multicore is designed to improve the performance of certain software products. Not all customers or software applications will necessarily benefit from the use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. AMD’s numbering is not a measurement of clock speed.
[2] Elite t655 Thin Client offers Windows 10 IoT 21H2, ThinPro 8.0, and Smart Zero Core.
[3] Mounting hardware sold separately.
[4] Peripherals sold separately or as optional features. Compatible with E24m G4 FHD USB-C Conferencing Monitor, E24u G4 FHD USB-C Monitor, E27u G4 QHD USB-C Monitor, E27m G4 QHD USB-C Conferencing Monitor, and USB-C Dock G5.
[5] 4K content required to view 4K images. Displays are sold separately and are not included.
| Operating system | IGEL OS |
|---|---|
| Processor | AMD Ryzen™ Embedded R2314 (up to 3.5 GHz max boost clock, 2 MB L2 cache, 4 cores, 4 threads) |
| Graphics (integrated) | AMD Radeon™ Graphics |
| Memory | 8 GB DDR4-3200 MT/s (2 x 4 GB) Transfer rates up to 3200 MT/s. |
| Internal Storage | 64 GB eMMC |
| Ports | 1 SuperSpeed USB Type-A 5Gbps signaling rate; 1 SuperSpeed USB Type-A 10Gbps signaling rate; 1 3.5 mm audio jack |
| I/O Port location | Front |
| Network interface | Realtek RTL8111HSH-CG GbE |
| Wireless | Realtek Wi-Fi 6 RTL8852BE (2x2) and Bluetooth® 5.3 wireless card |
| Audio | Internal amplified speaker system for basic audio playback |
| Keyboard | USB Keyboard |
| Pointing device | Wired 320M Mouse |
| Power | Smart 45 W External AC power adapter |
| Sustainable impact specifications | Low Halogen [8] |
| Software included | Device Manager; Easy Shell; Easy Tools; ThinUpdate; True Graphics; Cloud Endpoint Manager; Microsoft AVD; Write Manager |
| Warranty | 1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Audio | Internal amplified speaker system for basic audio playback |
|---|---|
| Browser supported | Mozilla Firefox (for models with ThinPro); Microsoft Edge (for models with Windows 10 IoT Enterprise LTSC 2021) |
| Certifications and compliances | EMC; EN 60601-1-2 |
| Country of origin | Mexico(ABA) |
| Dimension note (imperial) | Vertical orientation. |
| Dimensions (W x D x H) | 1.38 x 7.87 x 7.87 in |
| Display support | Up to 3 displays with three DisplayPort™ 1.4 video outputs provided at the back of the system. |
| End of Life CO2e (kg) | 1 |
| Energy Usage CO2e (kg) | 44 |
| Graphics | Integrated |
| Graphics (integrated) | AMD Radeon™ Graphics |
| I/O Port location | Back |
| Internal Storage | 64 GB eMMC |
| Keyboard | USB Keyboard |
| Manufacturer Warranty | 1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Material Type for item | FERT |
| Memory | 8 GB DDR4-3200 MT/s (2 x 4 GB) |
| Memory layout (slots & size) | 2 x 4 GB |
| Memory Slots | 2 SODIMM |
| Network interface | Realtek RTL8111HSH-CG GbE |
| Operating system | IGEL OS |
| Pointing device | Wired 320M Mouse |
| Ports | 2 USB Type-A 10Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 3 DisplayPort™ 1.4; 1 RJ-45; 1 audio-in/out |
| Power | Smart 45 W External AC power adapter |
| Processor | AMD Ryzen™ Embedded R2314 (up to 3.5 GHz max boost clock, 2 MB L2 cache, 4 cores, 4 threads) |
| Processor cache | 2 MB L2 |
| Processor core | 4 |
| Product long name specifications | Elite t655 Thin Client, IGEL OS, AMD Ryzen™, 8GB RAM, 64GB eMMC |
| Product short name specifications | Elite t655 Thin Client, AMD, 8GB RAM, 64GB eMMC |
| Production CO2e (kg) | 59 |
| Protocols | Citrix® HDX; Microsoft RFX/RDP; VMware Horizon® through RDP/PCoIP |
| Registration required | No |
| Software included | Device Manager; Easy Shell; Easy Tools; ThinUpdate; True Graphics; Cloud Endpoint Manager; Microsoft AVD; Write Manager |
| Standard memory note | Transfer rates up to 3200 MT/s. |
| Storage type | eMMC |
| Sustainability specifications | Low Halogen |
| TCO Certified | TCO Certified, generation 9 |
| Total CO2e (kg) | 100 |
| Total CO2e (kg) note | A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding. |
| Transportation CO2e (kg) | 0.5 |
| UNSPSC code | 43211506 |
| UPC number | 198990538525 |
| Weight | 2.5 lb (without stand); 2.6 lb (with stand) |
| Weight note (imperial) | Weight will vary depending on configuration. |
| Wireless | Realtek Wi-Fi 6 RTL8852BE (2x2) and Bluetooth® 5.3 wireless card |
| UPC number | 198990538525 |
|---|---|
| Dimension note (imperial) | Vertical orientation. |
| Dimensions (W x D x H) | 1.38 x 7.87 x 7.87 in |
| Country of origin | Mexico(ABA) |
| Material Type for item | FERT |
| UNSPSC code | 43211506 |
| Weight | 2.5 lb (without stand); 2.6 lb (with stand) |
| Weight note (imperial) | Weight will vary depending on configuration |
| Certifications and compliances | EMC; EN 60601-1-2 |
|---|---|
| Country of origin | Mexico(ABA) |
| End of Life CO2e (kg) | 1 |
| Energy Usage CO2e (kg) | 44 |
| Production CO2e (kg) | 59 |
| Sustainability specifications | Low Halogen |
| Sustainability specifications footnote number | [8] |
| Total CO2e (kg) | 100 |
| Transportation CO2e (kg) | 0.5 |
Specifications
[1] Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software, or BIOS updates to take full advantage of Windows functionality. Windows is automatically updated and enabled. High-speed internet and a Microsoft account are required. ISP fees may apply, and additional requirements may apply over time for updates.
[2] For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes.
[3] The graphics chipset uses part of the total system memory (RAM) for graphics performance. System memory dedicated to graphics performance is not available for other use by other programs.
[4] Optional or add-on feature.
[5] Wireless cards are optional or add-on features and require a separately purchased wireless access point and internet service. Availability of public wireless access points limited.
[6] The services are sold separately and are governed by the applicable terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the terms and conditions of service or the Limited Warranty provided with your Product.
[7] Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information.
[8] External power supplies, power cords, cables, and peripherals are not low-halogen. Service parts obtained after purchase may not be low-halogen.
[10] Easy Shell is currently available on Windows Embedded Standard 7E, Windows Embedded Standard 7P, Windows Embedded 8 Standard, Windows Embedded 8.1 Industry Pro, Windows 10 IOT Enterprise 2016 LTSC, and Windows 10 IoT Enterprise 2019.
[11] CEM requires Windows 10 IoT Enterprise LTSC 2016 or later, or ThinPro 7.2 operating system or later on endpoint and Internet access.
[13] Wi-Fi 6 is an optional feature that must be configured at the time of purchase. Wireless access point and Internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 (802.11ax) is backwards compatible with prior 802.11 specs.
[14] Multicore is designed to improve the performance of certain software products. Not all customers or software applications will necessarily benefit from the use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. AMD’s numbering is not a measurement of clock speed.
[15] AMD Max Boost frequency performance varies depending on hardware, software, and overall system configuration.
[63] TCO Certified is an ISO 14024 Type 1 sustainability label for IT products. Compliance with all criteria is independently verified.
